in autodesk vault professional 2012..
if you have done this:cracking the vault 1
and this:
cracking the vault 2
(which you should have done, since it was working ;-) )
and you are still getting:

Windows authentication failed with the data management server.
please make sure you are in the same domain as the data management server

reinstall ASP.NET:

For 32 bit:
"%windir%\Microsoft.NET\Framework\v2.0.50727\aspnet_regiis.exe" -i
For 64 bit:
"%windir%\Microsoft.NET\Framework64\v2.0.50727\aspnet_regiis.exe" -i

we changed this weekend from autodesk vault collaboration 2010 to vault professional 2012.
today morning we had the problem that: no files bigger than 50 mb can be downloaded
error message in vlog:

1/16/2012 9:26:11 AM Acquired license(xxx) for username(xxx), userId(xxx), host(xxx).
1/16/2012 9:26:12 AM *******************************************************************
Error: Soap Exception ( mesg-id = 634623027724824388 )
Exception: DownloadFileSizeExceedsServerLimit [1101]
Stacktrace:
Server stack trace:
at Connectivity.Document.BusinessLogic.FileBL.DownloadFilePart(Int64 fileIterationId, Int64 firstByte, Int64 lastByte, Boolean allowSync)
at Connectivity.Document.Services.FileService.DownloadFilePart(Int64 fileIterationId, Int64 firstByte, Int64 lastByte, Boolean allowSync)
at System.Runtime.Remoting.Messaging.Message.Dispatch(Object target, Boolean fExecuteInContext)
at System.Runtime.Remoting.Messaging.StackBuilderSink.SyncProcessMessage(IMessage msg, Int32 methodPtr, Boolean fExecuteInContext)

Exception rethrown at [0]:
at System.Runtime.Remoting.Proxies.RealProxy.HandleReturnMessage(IMessage reqMsg, IMessage retMsg)
at System.Runtime.Remoting.Proxies.RealProxy.PrivateInvoke(MessageData& msgData, Int32 type)
at Connectivity.Document.Services.FileService.DownloadFilePart(Int64 fileIterationId, Int64 firstByte, Int64 lastByte, Boolean allowSync)
at Connectivity.Web.Services.DocumentService.DownloadFilePart(Int64 fileId, Int64 firstByte, Int64 lastByte, Boolean allowSync)

first step: just one user, or more? all were affected

i found this entry on cracking the vault
and was wondering if this could be the solution. during research i found also this and this hint did the trick.
in web.config i found the section, which was obviously deprecated, but with IIS7 it seems to be back


 <!-- set maximum incoming message size to 50MB (51200KB/52428800B)
           NOTE: the values in these locations must match:
                         microsoft.web.services3/messaging/maxMessageLength/@value (in KB)
                         system.web/httpRuntime/@maxRequestLength (in KB)
                         system.webServer/security/requestFiltering/requestLimits/@maxAllowedContentLength (in B)
      -->
    <httpRuntime maxRequestLength="512000" executionTimeout="1000"/>

i adjusted the setting to 500 mb to check it. iisreset and everything was working fine again.
since comments on cracking the vault are closed for this issue, i made a seperate blog entry, for people who struggle with the same problem.
let me know if it helped you.
